| Modèles |
PSS-2005 |
PSS-3203 |
| SORTIE |
| Tension |
0~20V |
0~32V |
| Courant |
0~5A |
0~3A |
| OVP |
0~21V |
0~33V |
| LOAD REGULATION |
| Voltage |
< 3mV ( < 5mV rating current > 3A) |
| Current |
< 3mA ( < 5mA rating current > 3A ) |
| LINE REGULATION |
| Voltage |
< 3mV |
| Current |
< 3mA |
| RESOLUTION |
| Voltage |
10mV |
| Current |
1mA ( 2mA, rating current >3A ) |
| OVP |
10mV |
| PROGRAM ACCURACY (25±5° C) |
| Voltage |
< 0.05% + 20mV |
| Current |
< 0.1% + 5mA (10mA, rating current> 3A) |
| OVP |
< 0.05% + 20mV |
| RIPPLE & NOISE (20Hz ~ 20MHz) |
| Voltage |
Ripple≦1mVrms / 3mVp-p
Noise≦2mVrms / 30mVp-p |
| Current |
< 3mArms ( < 5mArms, rating current > 3A ) |
| TEMPERATURE COEFFICIENT (0~40° C ) |
| Voltage |
< 100ppm + 3mV |
| Current |
< 100ppm + 3mA |
| READBACK RESOLUTION |
| Voltage |
10mV |
| Current |
1mA ( 2mA, rating current > 3A ) |
| READBACK ACCURACY (25±5° C) |
| Voltage |
< 0.05% + 10mV |
| Current |
< 0.1% + 5mA (10mA rating current > 3A) |
| READBACK TEMPERATURE COEFFICIENT |
| Voltage |
< 100ppm + 10mV |
| Current |
< 100ppm + 5mA ( + 10mA rating current > 3A ) |
| TEMPS DE RESPONSE |
| Voltage Up 10%~90% |
< 100mS |
| Voltage Down 90%~10% |
< 100mS ( ≧10% rating load ) |
| DERIVE |
| Voltage |
< 100ppm + 10mV |
| Current |
< 150ppm + 10mA |
